    GYTA53 Fiber Optic Cord Doubel Sheath Armoured Flame Retardant Direct Buried Cable

    Ask Lasest Price
    Brand Name : TTI
    Model Number : GYTA53
    Certification : CE/ISO9001
    Price : Negotiable
    Payment Terms : L/C, T/T, ,Paypal
    Supply Ability : 5000m /day
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    GYTA53 Fiber Optic Cord Doubel Sheath Armoured Flame Retardant Direct Buried Cable

    Fiber Optic Cable GYTA53 Doubel Sheath Double Armoured Flame Retardant Direct Buried Cable


    Characteristics:


    · Good mechanical and temperature performance.


    · Special tube filling compound ensure a critical protection of fiber.


    · Crush resistance and flexibility.


    · PSP enhancing moisture-proof.


    Applications:

    ·Adopted to outdoor distribution and direct burial.

    ·Adopted to trunk power transmission system.

    ·Access network and local network in high electromagnetic interfering places.

    Specification


    No. of fibers6F12F24F36F48F72F96F144F
    No. of tubes112346812
    fibers per tube6661212121212
    Filler Rod54232000
    Tube diameter (±0.1mm)2.02.02.02.02.02.02.02.0
    Thickness of loose tube
    (±0.05mm)
    0.30.30.30.30.30.30.30.3
    Inner sheath diameter
    (±0.2mm)
    9.29.29.29.29.29.210.813.2
    Thickness of inner diameter
    (±0.2mm)
    1.01.01.01.01.01.01.01.0
    Outer diameter (±0.5mm)13.813.813.813.813.813.815.618.2
    Thickness of out diameter
    (±0.2mm)
    1.71.71.71.71.71.71.71.8
    Loose tubeMaterialPBTColorStandard spectrum
    Filler rodMaterialPPColorNatural
    Central strength memberMaterialFRPDiameter2.0mm±0.1mm
    Water blcoking systemMaterialWater blocking tape
    Inner armorMaterialAluminum tape
    Inner sheathMaterialPEColorBlack
    Rip cordQty2pcsColorWhite
    Outer armorMaterialCorrugated steel tape
    Outer sheathMaterialPEColor

    Product Pictures
