    LC/APC SM 9/125 G657A PVC LSZH Fiber Pigtail 1m 2m 3m

    Ask Lasest Price
    Brand Name : TTI
    Model Number : Fiber Optic Pigtail
    Certification : CE
    Price : Negotiable
    Payment Terms : D/A, D/P, T/T, , ,
    Supply Ability : 10000 pieces
    Delivery Time : 5-8 Work Days
    • Product Details
    • Company Profile

    LC/APC SM 9/125 G657A PVC LSZH Fiber Pigtail 1m 2m 3m

    FTTH SC UPC 50/125 OM4 Multimode Violet Fiber Optic Pigtail


    Patch cord pigtail, is in the end of a fiber optic cable plus fiber connector, the other end of the original state, to achieve optical network equipment and equipment, equipment and cable between the active connection, simple, convenient and fast. It is one of the essential passive products for optical network construction.

    TTI can provide all kinds of patch cord pigtail products; the transmission mode, optical cable type and connector type can be arbitrarily matched. It has the advantages of stable transmission, high reliability and customization; it is widely used in optical network scenarios such as central office, FTTX and LAN etc.

    1. Feature


    (1) Low insertion loss and back reflection loss

    (2) Good echangeability

    (3) Good Durability

    (4) High temperature stability

    (5) Standard: Telcordia GR-326-CORE


    2. Application
    (1) FTTH, LAN, PON & Optical CATV, Local ring net

    (2) Optical fiber communication system

    (3) Optical fiber test equipment

    (4) Optical fiber sensor

    (5) Industry and military application

    3. Speciafication
    LC/APC SM Fiber Optic Pigtail
    Fiber Mode
    SM/MM
    Fiber Count
    Simplex/Duplex
    Fiber Grade
    Bend Insensitive
    Cable Diameter
    0.9 mm
    Cable Jacket
    PVC/LSZH
    Parameter
    SC/LC/FC/ST/MPO/DIND4/MU Connector
    SM
    MM
    PC
    UPC
    APC
    PC
    Insertion loss
    ≤0.25dB
    ≤0.25dB
    ≤0.25dB
    ≤0.25dB
    Return loss
    ≥50dB
    ≥55dB
    ≥60dB
    /
    operating wavelength
    1310nm, 1550nm
    850nm, 1300nm
    Ferrule Concentricity
    ≤1um
    ≤4um
    Wavelength
    1310 nm/1550 nm
    Durability
    >1000 Times
    Working temperature
    -40~85°C
    Storage temperature
    -40~85°C

    4. Product Details



    5. FAQ:


    1. Why choose TTI FIBER ?
    (1) Professional manufacturer: Low MOQ, free samples are available.
    (2) Quality assurance:Stable high quality.
    (3) Customers solutions:Quick.
    (4) Win-Win Price:Save much costs, bring more benefits for customers.

    2. Do you accept OEM,ODM?
    Yes, we accept them .

    3. Can you print our LOGO?
    Sure, Your LOGO can be printed on the boxes , or products.

    4. What's the method of shipment?
    We accept all shipment , such as Delievery,ocean transport, land transport , airport transport.

    5. What's the Payment?
    We accept all online payments .
