    LC Duplex 3.0mm Fiber Optic Connector with 45degree Bent Boot

    Ask Lasest Price
    Brand Name : TTI
    Certification : ROHS, SGS
    Model Number : FC-Bent
    Price : Negotiable
    Delivery Time : in 2-4 days
    Payment Terms : T/T, , Monthly settlement
    Supply Ability : 10000pcs/Day
    • Product Details
    • Company Profile

    LC Duplex 3.0mm Fiber Optic Connector with 45degree Bent Boot

    LC Duplex 3.0mm Fiber Optic Connector with 45degree Bent Boot


    Qick Detail:

    1. Name: OM3 Fiber connector
    2. Ferrule size: 1.25mm, 2.5mm
    3. Ferrule End-face: APC UPC
    4. Cable diameter: 0.9mm, 2.0mm, 3.0mm
    5. Type: simplex, duplex
    6. Material: Plastic, Zinc Alloy, Bronze

    Features:

    1. Easy installation
    2. Competitive price
    3. Telcordia style boots
    4. Good durability

    Applications:

    1. Telecommunication
    2. Computer networks
    3. CATV networks
    4. Active device termination

    Specification:


    Insertion lossSM≤0.20 dB
    MM≤0.25dB
    Return lossP C≥50 dB
    UPC≥55 dB
    APC≥65 dB
    Durability<0.20 dB typical change, 1000 mating
    Ferrule hole sizesSM: 125.0+1/-0umconcentricity:≤1.0um
    125.5+1/-0um≤1.0um
    126.0+1/-0um≤1.0um
    MM:125 umconcentricity:1≤3 um
    127 um≤3 um
    128 um≤3 um
    Operating temperature-40~80°C

    Ordering Information:


    Step 1: Connector Type: FC,SC,LC,ST,MTRJ,MU,MPO,D4,DIN,SMA

    Step 2: Connector size: 0.9mm, 2.0mm, 3.0mm

    Step 3: Ferrule End-face: PC, UPC, APC

    Step 4: Core Type: Single-mode (SM:9/125um), Multimode (MM:50/125um,62.5/125um)

    Step 5: Boot color: Black, Blue, White, Red, Yellow, Green, Beige, Aqua


    Shipping:

    1. Door to Door: by express (such as DHL, UPS, TNT, FedEx etc.)
    2. Airport to Airport: by air
    3. Seaport to Seaport: by sea (our location Shenzhen is a seaport.)

    Our service:

    1. Standard and customized OEM products from small to large quantity are welcome.
    2. Compliance with global environmental industry with RoHS and SGS standards.
    3. All products are 100% fully tested by our technical expertise.
    4. We could add customer's logo in the label.
