ODVA -LC Duplex IP67 Fiber Optic Cable Sealed Circular

Sealed Circular IP 67 ODVA Duplex LC fiber patch cable assemblies are available in both single mode and multimode version, this ODVA LC is a typical outdoor use fiber cable, suitable for different temperature and weather, especially ideal for FTTA and harsh environment use. our IP 67 ODVA LC duplex cables are designed as per IEC 61076-3-106 interfaces standard, integrated with our quality LC fiber connectors with loss optical loss; and we designed a rugged and armored PE jacketed optical cable body. we have these ODVA LC in 9/125 LC/UPC, 50/125 OM2/OM3/OM4 LC/UPC and 62.5/125 OM1 LC/UPC. cable assemblies can be custom made in ODVA Duplex LC to Breakout dual LC, or ODVA LC to other popular connectors.

The CO FO 2 Fiber BO Single mode LC Duplex ODVA-LC cables are perfect solution for industrial and harsh environment use to prevent from the moisture, sunshine, gases and liquid. they are with strong PE jacket and armored structure cable, together with circular sealed connector body and dust caps, they can function under any weather conditions. we are supplying these cables at very competitive prices and fast delivery. custom made ODVA LC cables are available on request.

Specs:
Cable Type OFNR
Mode Singlemode
Connector Type (End A) LC
Connector Type (End B) LC
Connector Style (End A) Duplex
Connector Style (End B) Duplex
Fiber Channel No
Cable Assembly Type LC Duplex to LC Duplex, LC to LC
Product Type Cable Assembly
Number of Fibers 2
Cable Buffering Tight Buffer
Number of Connectors (End B) 2
Number of Connectors (End A) 2
Connector Color (End A) Beige
Connector Color (End B) Blue
Cable Color Black
Boot Type (Left) Standard
Boot Type (Right) Bend Limiting
Boot Color (Left) Black
Boot Color (Right) Blue
Ferrule Material Zirconia
Outside Cable Diameter 7.5mm[.295in]
Flammability Rating OFNR (Riser) Jacket
Cost effective solution for in house termination
IP67 Water immersion and Dust protection for hash environment
Wide range of operational temperature for outside plant -40oC/+70
Wide range of cables to be used, 5-8mm OD cable with two 2.0mm to 3.0mm jacketed subunits
Chemical Resistance
Intermatable to other Industrial LC adaptor per IEC 61076-3-106
Simple assembly requiring no special tools
Durable mechanical mating, minimum of 500 matings

Technical Data

Packing and Shipping :

Founded in 2013, TTI Fiber Communication Tech. Co., Ltd., is a professional manufacturer specialized in Fiber optic products for 14 years.

Our factory located in Shenzhen, China, covers an area of 12,000 square meters and has obtained ISO 9001, ISO 14001, REACH, RoHS, CE and CPR certificates and so on.

We have a wide range of fiber optic products, including Fiber Optic Cable, Fiber Optic Patch Cord, Fiber Optic Splitter, Fiber Optic Patch Panel, FTTx products, etc. We also provide professional Fiber Cabling Solutions and one-stop OEM & ODM service.

Our main markets are in North America, South America, Europe, Africa and Asia. Our reliable quality and sincere service are highly recognized by our clients all over the world.

We have cooperated with Global 500 top brands on FTTx products, and more than 30 well-known brand clients in fiber optic industry for 10 years. Our products are exported to over 100 countries.

We are committed to providing our clients with the best support, regardless of their business scale. Our expertise and knowledge of market trends, enables us provide technical support and matched solutions on fiber optic products. We are proud of providing excellent quality, competitive price and timely delivery.

Based on our quality assurance program we give you outstanding quality of fiber optic cable assemblies. Quality has always made TTI Fiber stand out.

Our key objective is to solve our customers and technical challenges by working in partnership to design and manufacture outstanding products. We strive for 100% customer satisfaction.

TTI Fiber provides qualified technical solutions and immediate service response when you need it the most.

We not only sell products. We are offering good service and professional support.

Choose TTI, to make your Internet Expedite!
