    Yellow Fiber Optical Splitter Sc Apc 1x64 Loss For Communication Systerm

    Ask Lasest Price
    Brand Name : TTI
    Model Number : FBT
    Certification : CE / ROHS
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, , ,PAYPAL
    Supply Ability : 1000 pieces / week
    Delivery Time : 5-7 work days
    • Product Details
    • Company Profile

    Yellow Fiber Optical Splitter Sc Apc 1x64 Loss For Communication Systerm

    fiber optical splitter sc apc 1x64 loss for communication systerm


    FBT Fiber Optic Splitter is a type of optical power management device that is fabricated using Fused Biconical Tape technology.


    Feature


    Low Excess loss


    Various Coupling Ratio


    Environment stable


    Single mode and multi mode available


    Application

    Long-haul Telecommunications

    CATV Systems & Fiber Optic Sensors

    Fiber Optic communication system

    Local Area Network


    Specification


    Parameters1×21×41×81×161×32
    Operating Wavelength (nm)1310/1490/1550
    Fiber TypeG657A1 or customer specified
    Insertion Loss (dB)(P/S Grade)3.8/4.07.1/7.310.2/10.513.5/13.717/17.4
    Loss Uniformity (dB)0.40.60.81.21.5
    Polarization Dependent Loss(dB)0.20.20.20.250.3
    Return Loss (dB) (P/S Grade)55/5055/5055/5055/5055/50
    Directivity (dB)5555555555
    Wavelength Dependent Loss (dB)0.30.30.30.50.5
    Temperature Stability (-40~85 ℃)(dB)0.40.40.40.50.5
    Operating Temperature (℃)-40~85
    Storage Temperature (℃)-40~85
    Device Dimension (mm)40×4×440×4×440×4×450×4×450×7×4
    Module Dimension (mm)100×80×10100×80×10100×80×10120×80×18140×115×18
    Mini-Module Dimension (mm)50×7×450×7×450×7×460×12×480×20×6
